Features
- 26-in/28-out USB-C audio interface for Mac and Windows.
- 8 microphone/line-level inputs.
- 4K analogue enhancement, Polarity Invert, High-Pass Filters and 48V Phantom Power per channel.
- Configurable analogue insert points for inputs 1 and 2, great for tracking with analogue gear
- Inputs 1 and 2 are switchable to instrument-level.
- Line inputs bypass preamp – perfect for integrating external preamps.
- 10 balanced line outputs.
- Alternative speaker switching.
- +9 dBu /+24 dBu output level configuration options for pairs 1&2 and 3&4 to best match your monitors.
- DC-coupled outputs are capable of sending control voltages to synthesisers and modular rigs.
- 2 independent, powerful headphone outputs with dedicated level controls.
- 3 mode options to suit different headphone impedances – Standard, High Sensitivity, High Impedance.
- Create custom headphone mixes.
- Re-purpose as line outputs.
- Dedicated Talkback input with Listen Mic Compressor (LMC).
- Talkback input can also be used in LINE mode for the creative processing of stems through the LMC when producing and mixing.
- +24 dBu operating level for inputs and outputs – perfect for integrating professional outboard gear as hardware inserts.
- 16 channels of ADAT I/O at 44.1/48 kHz, 8 channels at 96 kHz.
- 2 channels of S/PDIF (coaxial or optical).
- MIDI I/O on 3.5 mm TRS jacks.
- Flexible clocking options – internal (clock signal available on Word clock output), or clock from incoming ADAT or S/PDIF.
- Next-generation 32-bit/192 kHz converters. Class-leading audio performance in every area:
- Best-in-class low-noise microphone preamps with outstanding –130.5 dBu EIN and 67 dB gain range for working with any microphone.
- Best-in-class 120 dB dynamic range across all inputs & headphone outputs.
- Best-in-class 125 dB dynamic range on monitor and line outputs.
- SSL 18 Low-Latency Mixer powered by SSL 360.
- Comprehensive management of all inputs and outputs onto the SSL 18 low-latency mixer.
- Create the control room mix, plus an additional 4 custom monitor mixes with ease – HP A (stereo), HP B (stereo), LINE 3-4 (stereo or dual mono).
- Flexible Mirror Routing system to route any input or aux master directly to an output – perfect for feeding personal monitoring systems, external metering and outboard FX.
- Customise the monitoring section front panel buttons to suit your workflow.
- Save/Load SSL 18 Mixer profiles for various workflows – e.g. create tracking templates, mixing templates etc.
- Stereo Loopback with selectable loopback source.
- SSL Production Pack Software included – worth over Rs. 120,000
